Canoga Perkins L311

The Model L311 is a managed UTP-to-Fiber Media Converter that extends 10BASE-T UTP segments with fiber optic cable. The L311 extends the interconnection between switches or stations up to 100km.


10Base-T To Fiber Media Converter Canoga Perkins L311

Canoga Perkins L311 / 1230 37 Media Converters -
10/100BASE-T to Fiber, Gigabit Ethernet, with Sideband Management


Features
  • Full Duplex 10Mbps Ethernet Operation up to 120km
  • Support for 1310nm, and 1550nm Optics
  • Multimode and Single Mode Fiber Optic Media Support
  • Stand Alone Enclosure and Rackmount for
    UCS 1000/1001/1002
  • Side-Band Link Management with VT-100
    Support for Point-to-Point Applications
  • Link Loss Forwarding and Remote Fault Alarms
  • Remote and Local User Port Interface Status
  • Modular, Hot Swappable, and Field Interchangeable
  • Normal/Crossover Switch
  • NEBS Level 3 Compliant

Canoga Perkins L311
10Base-T To Fiber
Media Converter
Model L311

L311 Standalone


Description

The Canoga Perkins L311 is a managed UTP-to-Fiber Media Converter. It extends 10BASE-T UTP segments with fiber optic cable. The L311 extends the interconnection between switches or stations up to 100km. The L311 is especially suited for the long-distance extension of Full Duplex LAN segments. It supports 1310nm MM/SM, and 1550nm SM optics,
and works with all popular sizes of single mode and multimode fiber optic cables.

The Canoga Perkins L311 features management capabilities via Side-Band Management Channel (SBMC) independent of customer data. This user-enabled channel enables the exchange of commands and control between the local and remote link partners. A serial port for VT100 access is also provided for point-to-point applications.

A Link Loss Forwarding (LLF) fiber break propagation feature allows optical signal loss at the receiver to be detected as a UTP port management agent.

Primary application is the interconnection of 10Mbps Enterprise Switches and Service Provider Backbone Networks, using the fiber optic based, SNMP manageable Universal Chassis System (UCS). Within the UCS platform, the L311 addresses the Service Providers' requirements for Transparent LAN Services across a widely dispersed customer environment, and physical plant.


L311-XXXX UTP to Fiber Ethernet Media Converter w/ Sideband mgt., RJ45




Fiber Optic Options


Canoga Perkins L311-1111 10Mbps 850nm MM with ST Connector 11db
Canoga Perkins L311-1311 10Mbps 1310nm SM with ST Connector 10db
Canoga Perkins L311-1321 10Mbps 1310nm SM with ST Connector 20db
Canoga Perkins L311-1331 10Mbps 1310nm SM with ST Connector 20db WWDM
Canoga Perkins L311-1431 10Mbps 1480nm SM with ST Connector 20db WWDM
Canoga Perkins L311-1731 10Mbps 1543nm SM with ST Connector 26db WWDM
Canoga Perkins L311-1831 10Mbps 1557nm SM with ST Connector 26db WWDM
